CHARACTERISTICS
Voltage Rating Uo/U
15kV
Test Voltage
30.5kV
Ambient Temperature
Fixed: -40°C to +105°C
Flexed: -25°C to +105°C
Minimum Bending Radius
Fixed: 12 x overall diameter
Flexed: 15 x overall diameter
Standards & References
ASTM B3 Soft or Annealed Copper Wire
ASTM B8 Concentric-Lay-Stranded Copper Conductors
ASTM B33 Standard Specification for Tin-Coated Soft or Annealed Copper Wire
ASTM B496 Compact Round Concentric-lay-standard copper
UL 1072 Medium-Voltage Power Cables
UL 1685 FT4 Vertical-Tray Fire Propagation and Smoke Release Test
UL 1685 Vertical-Tray Fire Propagation and Smoke Release Test
ICEA S-93-639 (NEMA WC 74) 5-46 KV Shielded Power Cable
IEEE 1202 FT4 Flame Test (70,000) BTU/hr Vertical Tray Test
